Set up a Node.js app for a website with Apache on Ubuntu 16.04
Execution of Node.js scripts as a service
Although open source JavaScript Node.js scripts can be run from the command line using screen, running the scripts as a service using the process manager PM2 gives the scripts a more robust set of behaviours. When run as a service this way, the scripts will automatically restart if the server is rebooted or the script crashes.
PM2 is a process manager for Node.js, with a wide range of features you can use to control and manage your Node.js scripts. Visit the official PM2 website for more information on using PM2.
Requirements
- A Cloud Server running Linux (Ubuntu 16.04).
- A working domain name which links to the server.
- A functional Apache web server installed and running.
Thanks to free starting credit, you can test the IONOS cloud server for 1 month free of charge (or until the credit is used up) and experience the perfect combination of performance and security!
![](https://www.ionos.co.uk/digitalguide/fileadmin/DigitalGuide/IAS/CTAs/SEO_Digital_Guide_Mobile_nur-Nlement_900x750.png)
Install Node.js
Update your server’s packages and install curl with the following commands:
sudo apt-get update
sudo apt-get install curl
Download the Node.js personal package archive (PPA). This contains a more recent Node.js version than the Ubuntu repositories:
curl -sL https://deb.nodesource.com/setup_6.x -o nodesource_setup.sh
Run the nodesource_setup.sh command to add the PPA to your server’s package cache:
sudo bash nodesource_setup.sh
This script will update the server automatically. There is no need to run apt-get update a second time.
Afterwards, install Node.js:
sudo apt-get install nodejs
This will automatically install npm as well.
Finally, install the build-essential package for npm:
sudo apt-get install build-essential
Create a sample Node.js application
For this example, we will begin by creating a separate directory in your website’s document root for housing Node.js applications:
sudo mkdir /var/www/html/nodejs
Create the file hello.js in this directory:
sudo nano /var/www/html/nodejs/hello.js
Add the following example content to the file:
#!/usr/bin/env nodejs
var http = require('http');
http.createServer(function (request, response) {
response.writeHead(200, {'Content-Type': 'text/plain'});
response.end('Hello World! Node.js is working correctly.\n');
}).listen(8080);
console.log('Server running at http://127.0.0.1:8080/');
Save and exit the file and make the file executable:
sudo chmod 755 hello.js
Install PM2
Use npm to install PM2 with the command:
sudo npm install -g pm2
Start the hello.js example script that you’ve just created with the command:
sudo pm2 start hello.js
As root add PM2 to the startup scripts, so that it will automatically restart if the server is rebooted:
sudo pm2 startup systemd
- Automatic backup and easy recovery
- Intuitive scheduling and management
- AI-based threat protection
![](https://www.ionos.co.uk/digitalguide/fileadmin/DigitalGuide/IAS/CTAs/SEO_Digital_Guide_Mobile_nur-Nlement_900x750.png)
Configure Apache
To access the Node.js script from the web, install the Apache modules proxy and proxy_http with the commands:
sudo a2enmod proxy
sudo a2enmod proxy_http
Once the installation is complete, restart Apache for the changes to take effect:
sudo service apache2 restart
Next, you will need to adjust the Apache proxy configurations. The following directives need to be inserted into the VirtualHost command block in the site’s main Apache configuration file.
By common convention, this Apache configuration file is usually /etc/apache2/sites-available/example.com.conf on Ubuntu.
The location and filename of a site’s Apache configuration file can vary.
Edit this file with your editor of choice, for example with the command:
sudo nano /etc/apache2/sites-available/example.com.conf
Scroll through the file until you find the VirtualHost command block, which will look like:
<VirtualHost *:80>
ServerName example.com
<Directory "/var/www/example.com/html">
AllowOverride All
</Directory>
</VirtualHost>
Add the following to VirtualHost command block:
ProxyRequests Off
ProxyPreserveHost On
ProxyVia Full
<Proxy *>
Require all granted
</Proxy>
<Location /nodejs>
ProxyPass http://127.0.0.1:8080
ProxyPassReverse http://127.0.0.1:8080
</Location>
Be sure to put these lines outside any Directory command blocks. For example:
<VirtualHost *:80>
ServerName example.com
ProxyRequests Off
ProxyPreserveHost On
ProxyVia Full
<Proxy *>
Require all granted
</Proxy>
<Location /nodejs>
ProxyPass http://127.0.0.1:8080
ProxyPassReverse http://127.0.0.1:8080
</Location>
<Directory "/var/www/example.com/html">
AllowOverride All
</Directory>
</VirtualHost>
Save and exit the file, then restart Apache for the changes to take effect:
sudo services apache2 restart`
After restarting Apache, you can test the application by viewing it in a browser. You should see the following message from the test file you created earlier:
Hello World! Node.js is working correctly.
